| Capacity | 890 lt/dk |
| Suction/Discharge Size | 3" |
| Main Body | Aluminium-Cast iron-Cast Stainless Steel-Sheet Metal(hygienic |
| Diaphragms | Santoprene-Neoprene-BUNA-N-EPDM-Teflon-Viton |
| Ball Valves | Santoprene-Neoprene-BUNA-N-EPDM-Teflon-Viton |
| Ball Seats | Santoprene-Neoprene-BUNA-N-EPDM-Teflon-Viton |
| Air Inlet Size | 3/4" |
| Solids-Handling | 8mm |
| Suction Depth | 6m |
| Operating Pressure (Max.) | 7 bar |
| Delivery Height (Max.) | 70 m |
| Operation Temperature | -18 / + 1000C |
VP30 METHALIC BODY PUMP USER MANUAL
